Exb (C) 2-9 Series Explosion Proof Quarter Turn Electric Actuator

Short Description:

Explosion-proof electric actuators of the Ex series may switch valves by turning the output shaft 90 degrees. These actuators are mostly used to drive and regulate the angular stroke valve opening. applications for valves like butterfly valves, ball valves, plug valves, and others that are comparable. Range of EXC(CG) output torque is 35-80N.m. Electric actuators from the EX series that are explosion-proof can be found in a variety of industries, including those that deal with petroleum, chemicals, water treatment, shipbuilding, paper manufacturing, power plants, heating, and automatic building control.

Send email to us Download as PDF

Product Detail

Product Tags

Product Video

Advantage

Warranty: 2 years
Overload Protection: The power will automatically shut off when the valve jam occurs. Thus preventing further damage to the valve and actuator
Explosion-proof Rating: Ex d IIC T6 design and NEPSI & 3C certifications which satisfy the requirements in hazaradous locations.
Operational Safety: F insulation class, equipped with temperature control switch at the motor winding, to protect the motor running safety.
Voltage Protection: Protection against high and low voltage conditions.
Applicable valve:Plug valve; Ball Valve; Butterfly Valve,
Anti-corrosion Protection: Epoxy resin enclosure meets NEMA 4X, customer-special painting is available
Ingress Protection: IP67 optional: IP68；IP68 is defined as a rating of 7m underwater, impermeable for 72 hours
Fireproofing Grade: FLOWINN high temperature fire-proof cover for special use.

Standard Specification

Material of Actuator Body	Aluminum Alloy
Control Mode	On-off Type & Modulating Type
Torque Range	35-80N.m
Running Time	11-22s
Applicable Voltage	1 phase:AC/DC24V / AC110V / AC220V / AC230V /AC240V
Ambient Temperature	-25°C…..70 °C; Optional: -40°C…..60 °C
Anti-vibration Level	JB/T8219
Noise Level	Less than 75 dB within 1m
Ingress Protection	IP67 optional: IP68 ( Maximum 7m；Max:72 hours)
Connection Size	ISO5211
Motor Specifications	Class F, with thermal protector up to +135°C（+275°F); Optional : Class H
Working System	On-off Type: S2-15 min, no more than 600 times per hour start Modulating Type: S4-50% up to 600 times per hour start; Optional: 1200 times per hour
