EMT Series Integration Type Multi-Turn Electric Actuator

Short Description:

An electric actuator that can rotate beyond 360 degrees is known as a multi-turn electric actuator. The EMT series of multi-turn electric actuators is designed specifically for use with multi-turn or linear motor valves, such as gate valves, globe valves, and control valves, among others. Moreover, when combined with a 90-degree worm gearbox, it can operate quarter turn valves like butterfly valves, ball valves, and plug valves. FLOWINN offers a variety of multi-turn EMT series electric actuators, ranging from standard models suitable for basic industrial needs to intelligent models capable of configuration settings and intelligent feedback for various valve applications.

Send email to us Download as PDF

Product Detail

Product Tags

Product Video

Advantage

Warranty: 2 years
Motor Prptection: Equipped with two temperature sensors, an F-class insulated motor can prevent overheating. (Class H motor can be customized)
Anti Moisture Protection: It has a standard anti-moisture feature to protect internal electronics from condensation.
Absolute Encoder: It has a 24-bit absolute encoder capable of accurately recording up to 1024 positions, even in power loss mode. The motor is available in both integration and intelligent types.
High Strength Worm Gear and Worm Shaft: It is built with a high-strength alloy worm shaft and gear for extended durability. The meshing between the worm shaft and gear has been closely examined to ensure maximum efficiency.
High RPM output: Its high RPM makes it ideal for use with large diameter valves.

Performance Processor: The intelligent type uses a high-performance microprocessor for efficient and reliable monitoring of valve position, torque, and operational status.
Safe Manual Override: Manula override clutch to disengage motor and enables manual operation of the actuator
Infrared Remote Control: Integration and Intelligent type come with infrated remote control for easy menu access.
Non-Intrusive set up: The integration and intelligent types can be remotely controlled, and come with an LCD display and local control buttons/knobs for easy access. Valve position can be set without the need for mechanical actuation.
